| Chassis |
Surface Mount |
| Mounting Type |
Surface Mount |
| Contact Finish Mating |
SN ON CU |
| Contact Materials |
BRASS |
| Insulation Materials |
Glass-Filled Polybutylene Terephthalate |
| Series |
Neopixel |
| Size/Dimensions |
5.00mm Lx5.00mm W |
| JESD-609 Code |
e3 |
| Part Status |
Active |
| Moisture Sensitivity Level (MSL) |
5 (48 Hours) |
| Connector Type |
Board Connector |
| Maximum Operating Temperature |
85°C |
| Minimum Operating Temperature |
-40°C |
| Color |
Red, Green, Blue (RGB) |
| Number of Rows |
1 |
| Additional Features |
ROHS COMPLIANT |
| Total Number of Contacts |
1 |
| Terminal Pitch |
2.54mm |
| Number of Conductors |
ONE |
| Reference Standards |
UL, CSA |
| Reliability |
COMMERCIAL |
| Body Length/Diameter |
0.1 inch |
| PCB Number of Rows |
1 |
| PCB Contact Pattern |
RECTANGULAR |
| Body Width |
0.098 inch |
| Contact Gender |
MALE |
| Body Depth |
0.098 inch |
| Rated Current (Signal) |
3A |
| Contact Style |
SQ PIN-SKT |
| Contact Resistance |
20mOhm |
| Configuration |
Discrete |
| Insulation Resistance |
5000000000Ohm |
| Mating Contact Pitch |
0.1 inch |
| Body/Housing Style |
RECEPTACLE |
| Interface |
Serial (Shift Register) |
| Terminal Type |
SOLDER |
| Durability |
500 Cycles |
| Contact Finish – Terminal |
Tin (Sn) |
| Contact Pattern |
RECTANGULAR |
| Number of Light Emitting Diodes |
10 |
| LED Used |
SK6812 or WS2812 |
| Height |
1.6mm |
| Length – Terminal |
0.165 inch |
| RoHS Status |
ROHS3 Compliant |
