| Category | Sub-Category | Specifications |
|---|---|---|
| Multi-Core Processing | Configuration Options | – Dual-core: 800MHz Cortex-M7 + 240MHz Cortex-M33 – Single-core: Cortex-M33 only |
| Software Ecosystem | Development Tools | – MCUXpresso SDK with: • IDE integration • Pin/clock/peripheral configurators • Security/memory tools – Zephyr RTOS support |
| Networking | TSN Switch | – Industry’s first MCU with: • Gbps TSN switching • 5-port configuration (4x switch + 1x endpoint) – 50Gbps aggregate bandwidth |
| Protocol Support | – Industrial Ethernet: • Profinet/EthernetIP/EtherCAT • CC-Link IE Field/HSR – TSN Standards: • IEC 60802 compliant • OPC UA PubSub over TSN |
|
| Security | EdgeLock™ Secure Enclave | – Pre-provisioned security subsystem – ICG 2443 compliance – Secure boot with: • Hardware root-of-trust • Cryptographic acceleration – Physical monitoring: • Secure RTC • Tamper detection pins |
| Memory Architecture | On-Chip RAM | – 15MB SRAM (ECC-protected) – Dedicated TCM: • 512KB for Cortex-M7 • 256KB for Cortex-M33 |
| Category | Sub-Category | Specifications |
|---|---|---|
| Analog | ADC | – High-speed 16-bit ADC |
| Signal Processing | – Advanced timer/PWM – Delta-sigma demodulator |
|
| Environmental | Temperature Range | – Extended industrial: -40°C to +125°C |
| Certification | – AEC-Q100 automotive grade (optional) | |
| Packaging | Options | – 289 MAPBGA: 14×14mm, 0.8mm pitch – 144 MAPBGA: 10×10mm, 0.8mm pitch |
