描述
| Parameter | Details |
|---|---|
| Cores | Main core: 64 – bit LA264; Small core: 32 – bit LA132 |
| Main Frequency | Main core: ≥1.2GHz; Small core: 400MHz |
| Power Consumption | <1.0W (Supports dynamic frequency scaling) |
| High – speed I/O | USB2.01, OTG1, GMAC*1 |
| Other Interfaces | PRINTer, SCANNer, QSPI/SPI, eMMC, SDIO, ADC, I2C, UART, PWM, PMIO, GPIO, JTAG, etc. |
| Microarchitecture | Dual – issue out – of – order execution LA264; Single – issue LA132 |
| L1 Instruction Cache | Main core: 32KB; Small core: 4KB |
| L1 Data Cache | Main core: 32KB; Small core: 4KB |
| L2 Cache | Shared 256KB |
| Memory Controller | 8 – bit DDR4 – 1600 |
