| Contact Plating |
Copper, Tin |
| Chassis |
Through Hole |
| Package/Case |
DIP |
| Number of Pins |
14 |
| Number of Elements |
280 |
| Usage Level |
Industrial grade |
| Series |
HCMS-29xx |
| Published |
2002 |
| Size/Dimensions |
1.40Lx0.40W x 0.20 H 35.56mmx10.16mmx5.08mm |
| JESD-609 Code |
e2 |
| Part Status |
Active |
| Moisture Sensitivity Level (MSL) |
1 (Unlimited) |
| ECCN Code |
EAR99 |
| Terminal Finish |
Tin/Copper (Sn/Cu) |
| Maximum Operating Temperature |
85°C |
| Minimum Operating Temperature |
-40°C |
| Color |
Green |
| Additional Features |
TTL Compatible |
| Voltage – Rated DC |
5V |
| Number of Functions |
8 |
| Depth |
10.16mm |
| Operating Supply Voltage |
5V |
| Configuration |
5 x 7 |
| Interface |
Serial |
| Maximum Supply Voltage |
5.5V |
| Minimum Supply Voltage |
3V |
| Element Configuration |
Common Cathode |
| Power Dissipation |
2.4W |
| Forward Current |
800μA |
| Forward Voltage |
5V |
| Luminous Intensity |
114 μcd |
| Wavelength – Peak |
568 nm |
| Power Consumption |
2.4W |
| Number of Characters |
8 |
| Dominant Wavelength |
574 nm |
| Character Width |
2.11mm |
| Height |
5.08mm |
| Viewing Area (Height) |
3.71mm |
| Character Height |
3.81mm |
| Reach SVHC |
No SVHC |
| Radiation Hardening |
None |
| RoHS Status |
ROHS3 Compliant |
| Lead Free |
Lead Free |
