描述
| Category | Sub-Category | Specifications |
|---|---|---|
| Core Platform | Processor | – Arm® Cortex®-M33 @ 180MHz |
| Math Accelerator | – Digital Acceleration Unit (MAU) supporting: • Trigonometric functions • Division/reciprocal • Square/square root • Sine/cosine • Arctangent |
|
| Co-Processor | – SmartDMA for: • Parallel camera interfaces • Keyboard scanning |
|
| Memory | Flash | – Single-bank Flash: • Up to 1024KB with ECC • Single-bit correction/double-bit detection |
| Cache | – Cache Engine with 8KB RAM | |
| System RAM | – Up to 256KB RAM: • 8KB shared with cache • Configurable as 8KB ECC blocks • Single-bit correction/double-bit detection – All RAM retainable in Deep Power-Down mode |
|
| ROM | – Boot ROM (size not specified) |
| Category | Sub-Category | Specifications |
|---|---|---|
| Analog | ADC | – 4x 16-bit ADCs – Sampling rate: • 3.2 MS/s (16-bit mode) • 4.0 MS/s (12-bit mode) – Up to 82 input channels (package-dependent) – Integrated temperature sensor |
| DAC | – 1x 12-bit DAC @ 1 MS/s | |
| Comparators | – 3x high-speed comparators: • 8 input pins • 8-bit internal reference DAC – 1x LPCMP operational in Deep Power-Down mode |
|
| Amplifiers | – 4x OPAMP (without PGA) | |
| Timers | General Purpose | – 5x 32-bit async timers: • 4 capture/compare channels • PWM generation • External count input • DMA event triggering |
| Specialized | – Low-Power Timer – Frequency measurement timer – Windowed Watchdog – Wake-up Timer – MicroTick Timer (UTICK) – OS Event Timer – RTC (no external 32kHz input required) |
|
| Communication | Serial Interfaces | – 2x IPSPI – 4x LPI2C – 6x LPUART – 1x FlexCAN with FD |
| Security | Device Identity | – 128-bit UUID per RFC4122 v5 specification |
| Memory Protection | – Flash R/W/X permission control via MBC – Protected Flash Region (PFR) |
|
| Security Monitor | – Code Watchdog for execution flow verification – Glitch-protected key access (GlitchKey) – 6x passive tamper detection pins |
