描述
| Category | Sub-Category | Specifications |
|---|---|---|
| Core Platform | Processor | – Arm® Cortex®-M33 @ 96MHz |
| Interrupt Control | – Nested Vectored Interrupt Controller (NVIC) – Wake-up Interrupt Controller (WIC) |
|
| Memory | Program Memory | – 2MB Flash with ECC |
| System RAM | – 256KB SRAM with ECC and parity | |
| Wireless Subsystem | Processor | – Dedicated Arm® Cortex®-M33 core |
| Memory | – 256KB dedicated Flash for: • Certified NXP 15.4 stack • BLE firmware – 170KB dedicated SRAM |
|
| IEEE 802.15.4 | – IEEE 802.15.4-2015 compliant – -110dBm @ 250kbps RX sensitivity – Enhanced ACK timing – Dual PAN support |
|
| Bluetooth 5.0 | – BLE 5.0 2.4GHz radio – Supports 24 concurrent connections (any master/slave) – Channel Sounding support – Location Calculation Engine (LCE) for ranging – RX sensitivity: • -106dBm @ 125kbps (long range) • -102dBm @ 500kbps (long range) • -97.5dBm @ 1Mbps • -95dBm @ 2Mbps – TX power: Programmable up to +10dBm |
|
| Radio Features | – Data rates: 125/500kbps, 1/2Mbps – Modulation: 2-FSK, GFSK, MSK, GMSK – On-chip balun with single-ended bidirectional RF port |
| Category | Sub-Category | Specifications |
|---|---|---|
| Analog | ADC | – 16-bit SAR ADC @ 2MSPS (single-ended) |
| Comparators | – 2x high-speed analog comparators with 8-bit DAC | |
| Voltage Reference | – Programmable V<sub>REF</sub> (1.0V to 2.1V) | |
| Timers | PWM Timers | – 2x 6-channel 32-bit TPM with: • PWM generation • DMA support |
| Low-Power Timers | – 2x 32-bit LPTMR (configurable as timer/pulse counter) | |
| System Timers | – 4-channel 32-bit PIT with DMA – 56-bit timestamp timer – 32-bit RTC with: • 32-bit alarm • Independent power domain |
|
| Analysis | – Signal Frequency Analyzer (SFA) for: • Clock cycle/frequency measurement • Trigger interval analysis |
|
| Communication | Serial Interfaces | – 2x LPUART – 2x LPSPI + 1x MIPI-I3C – 2x LPI2C (SMBus 2.0 compliant) |
| CAN | – 2x FlexCAN with: • CAN 2.0B compliance • CAN FD support |
|
| Programmable I/O | – FlexIO module supports emulation of: • UART/I2C/SPI • Camera interface • LCD RGB control • PWM/waveform generation |
|
| GPIO | – 29 GPIO pins (48QFN package) | |
| System Peripherals | Power Management | – DC-DC converter with: • Buck mode • Bypass mode – Wake-up unit for power-down modes |
| DMA | – Asynchronous DMA controller with: • Per-channel security attribution (secure/non-secure) |
|
| Security | EdgeLock Secure Enclave | – Cloud-based certificate management (EdgeLock 2GO) – Secure boot/debug |
| Cryptography | – Symmetric encryption: • AES-128/192/256 (ECB/CBC/CTR/GCM/CMAC/CCM) – Asymmetric encryption: • ECC (NIST P-192/224/256/384/521, Curve25519) – Key exchange: • ECDH/SPAKE2+/JPAKE |
|
| Memory Protection | – PRINCE XEX module provides: • Flash access protection • Optional on-the-fly decryption |
