描述
| Parameter | Specification |
|---|---|
| CPU | ARM926EJ |
| CPU Speed Max (MHz) | 800 |
| RAM (KB) | 64 |
| Internal DRAM (MB) | 256 |
| Int. DRAM Type | DDR2L |
| NAND Interface | Yes |
| Graphic LCD Interfac. | MIPI DSI, LVDS, RGB |
| Graphics Controller/GPU | 2D GPU |
| Camera Interface | MIPI CSI2, Parallel |
| QSPI | 1 |
| USART | 13 |
| SPI | 6 |
| I2C | 13 |
| I2S | 1 |
| 10/100/1000 Ethernet MAC | 1 |
| Ethernet TSN Support | yes |
| USB Interface | 1 HS Host, 2 HS Host/Device |
| USB Type C support | no |
| CAN/CAN FD | 2 |
| Type of CAN module | CAN FD |
| SD/SDIO/SD/MMC | 2 |
| Class D Amplifier Output | Yes |
| ADC Channels | 8 |
| ADC Resolution (bits) | 12 |
| Crypto Engine | Yes |
| Secure Bootloader | Yes |
| Anti Tampering Impacts | 8 |
| Secure Key Storage (bits) | 10 Mbytes OTP |
| TempRange Min | -40 |
| TempRange Max | 105 |
| I/O Pins Max | 186 |
| PinCount | 243 |
| Package | TFBGA |
| Category | Details |
|---|---|
| Low System Cost and High Value Integration | • 800MHz ARM926EJ – S Core, 266MHz System/Memory Bus • 32 KB Data Cache and 32KB Instruction Cache |
| Memories | • 64 KB internal SRAM • 16 – bit DDR databus |
| Enhanced User Interface capability | • 24 – bit LCD Controller with overlays up to 1024×768 resolution • 2D Graphics Engine |
| Built – in Class D Amplifier | Built – in Class D Amplifier |
| Display/Camera Support | • MIPI – DSI Display Interface • LVDS Display Interface • RGB 24bit display interface • MIPI – CSI Camera Interface |
| Large number of connectivity options | • Single 10/100/1G Ethernet • One Quad/Octal SPI controller • Thirteen FLEXCOMs (USART, SPI and TWI/I2C) • Two High – speed USB Host + One High – speed Host or Device |
| Fully – integrated Security | • Secure Boot with on – chip Secure Key Storage (OTP) • Hardware Encryption Engine (TDES, AES and SHA) • FIPS compliant True Random Number Generator (TRNG) • Physical protection against tamper, 8 tamper detection pins |
| Rich Development Ecosystem | • Free mainline Linux® Distribution • MPLAB® X Integrated Development Environment and MPLAB® Harmony v3 |
| Optimized for Easy PCB Design and Low EMI | • TFBGA243, 16×16, 0.8 mm pitch – de – embedded ball – out • Power/GND balls placed and distributed for optimal decoupling |
