| Chassis |
Through Hole |
| Mounting Type |
Through Hole |
| Package/Case |
Module |
| Number of Pins |
9 |
| Published |
2007 |
| JESD-609 Code |
e3 |
| Part Status |
Active |
| Moisture Sensitivity Level (MSL) |
1 (Unlimited) |
| Connector Type |
ST |
| Terminal Finish |
Matte Tin (Sn) – with Nickel (Ni) barrier |
| Maximum Operating Temperature |
85°C |
| Minimum Operating Temperature |
-10°C |
| Application |
General Purpose |
| HTS Code |
8517.62.00.50 |
| Voltage – Supply |
3.3V, 5V |
| Supply Voltage |
3.3V |
| Maximum Output Current |
50mA |
| Operating Supply Voltage |
5V |
| Output Current |
50mA |
| Data Rate |
100Mbps |
| Rise Time |
1.9ns |
| Fall Time (Typical) |
1.6 ns |
| Wavelength – Peak |
1.3μm |
| Fiber Type |
50/125, 62.5/125, MMF |
| Fiber Optic Device Type |
TRANSCEIVER |
| Built-in Function |
AMPLIFIER |
| Operating Wavelength – Nom |
1308 nm |
| Transmitter/Detector Type |
LASER DIODE, PIN PHOTODIODE |
| Optical Power Output – Nom |
0.039mW |
| Communication Standard |
ATM, OC-3C, SONET |
| Height |
24.8mm |
| Length |
25.4mm |
| Width |
12mm |
| Radiation Hardening |
None |
| RoHS Status |
ROHS3 Compliant |
| Lead Free |
Lead Free |
