描述
| Category | Details |
|---|---|
| Specification | – Material: Copper alloy T=0.10mm – Dimensions: L5.20W1.00H1.28mm – PCB Footprint: (L1.00*W0.80mm)*2 – Plating: – Plating Au 0.05um min on overall – Underplating: 1.0-3.0um Ni overall |
| Product and Supply Features | – Contact resistance: 30 Milliohms Max – Mating Force: 7.50N Max – Unmating Force: 3.50N Min – Cable Size: Φ0.81mm – Durability test: 1500 cycles |
